Number of Axes Supported
3-12 axes
RAM
1G
Storage
32G SSD
USB Interface
USB2.0
Network Interface
1000Mbps
Vedio Output Interface
VGA,touch screen supported
I/O
120/O48
Pulse Frequency
1MHZ
Performance Indicator
The product stands EMI/Electrical fast transient immunity/Surge immunity tests and conforms to the fourth grade protection standards of GB/T 17626.5-2008.
Resistance to vibration conforms to the GB/T 2423.10-2008 Standards.
The product stands rigid temperature tests and conforms to the industrial standards of GB/T 2423.102-2008.
Analog Voltage Output
0-10V
Tool Measurement Mode
Auto measurement,Manual measurement
Tool Measurement Type
Fixed calibration,Mobile calibration,First calibration&Calibration after tool change
Compensation Type
Workpiece compensation,Screw error compensation,Backlash compensation,AQE compensation,Tool compensation
Internet（Ethernet）
LAN communication,Front USB interface,Two-way transmission between the system and PC
Supported File Format
*.g/*.nc/*.u??/*.demo/*.iso/*.eng/*.cut/*.dxf/*.plt/*.txt
WCS
Supporting WCS G54-G59 and extended WCSs
Processing Technology
Two-mark/ Three-mark photo mode, Offset compensation, Max. offset detection, CCD setting, Array function, Template matching pattern selection, Image match accuracy
Convenient Operation
Focal setting, Offset measurement, Scale override setting, Photo delay setting, Program editing, CCD enabled/disabled and Simulation machining
Number of CCD
Single CCD,Dual-CCD
Interpolation Algorithms;
